Pump hydraulic CBT replace Tractor pump Fiat 400e 500e 600e
This CBT series hydraulic product can be applied to tractor pump Fiat 400e 500e 600e.
CBT Series gear pump using a high-strength aluminum alloy extrusion shell, bearing capacity and high DU bearing floating side plate structure. With high pressure, high speed, simple structure, easy maintenance, reliable, long service life and so on.
Introduction and Features:
- Hanjiu pumps and motors are high volumetic efficiency and long life achieved by smart design and accurate control of machining tolerances
- Fine finished steel gears,Hi-resistant Extruded alluminum body, Hi-resistant Die cast alluminum cover(BAP2) or cast-iron cover(BHP2), Low-friction die casting alluminum bushes,and DU slide bearing,all these keep low pulsation,low noise and long life.
- Full option of shafts,flanges and ports as for European,German and America standards
- Nitrile seals as standard and viton seals available for high temperature application,high pressure shaft seals are also available.
- Motor and bi-direction pump available
- Available as multiple pump either of the same or different group
- We test 100% of the pumps and motors after assambling to ensure the high standard performance.
- Our team have worked in hydraulics for about 20 years. Our technical people are very skilled in producing gear pump.
- We have supplied to many world-famous company all over the world.
Specifications:
| Type | Displacement | Max.pressure | Max.speed | Min.speed |
| P1 | P2 | P3 |
| | cm3/rev | bar | bar | bar | r/min | r/min |
| CBT | 3 | 270 | 285 | 300 | 4000 | 800 |
| CBT | 4 | 270 | 285 | 300 | 4000 | 600 |
| CBT | 6 | 270 | 285 | 300 | 4000 | 600 |
| CBT | 8 | 270 | 285 | 300 | 3500 | 500 |
| CBT | 10 | 270 | 285 | 300 | 3000 | 500 |
| CBT | 12 | 270 | 285 | 300 | 3000 | 500 |
| CBT | 14 | 250 | 265 | 280 | 4000 | 500 |
| CBT | 16 | 250 | 265 | 280 | 4000 | 500 |
| CBT | 18 | 250 | 265 | 280 | 3600 | 400 |
| CBT | 20 | 220 | 235 | 250 | 3200 | 400 |
| CBT | 22 | 220 | 235 | 250 | 3000 | 400 |
| CBT | 25 | 200 | 215 | 230 | 3000 | 400 |
| CBT | 28 | 180 | 190 | 200 | 2500 | 400 |
| CBT | 30 | 160 | 170 | 180 | 2500 | 400 |
Applications:
Hydraulic system:36.9%; Agriculture machine:24.4%;
Constraction machine:19.6%; Automobile:12.3%5.Others:4.1%.
Shijiazhuang Hanjiu Technology Co., Ltd. We are specialized in producing hydraulic orbital motors, hydraulic steering Unit and other hydraulic products.
The products can be widely used for different kinds of Construction Equipments, Heavy equipments, Agricutural machines and Industrial machines etc.Machines like , Komatsu, Hitachi, Volvo, , , New holland, Massey ferguson, Fiat, MTZ, etc.
Overseas market like Southeast Asia, Middle East, South America, North America, Europe, Africa and other countries and regions.
welcome advice.
